The Quick Answer

XT90 is a high-current two-conductor connector used on battery and power connections. MT60 is a three-conductor connector used for motor phase wires. Julet and Higo-style waterproof families are used for low-current signals — display, throttle, pedal assist, brakes and hall sensors — and, in some motor plugs, for combined phase and hall connections.

The rule underneath all three: connector shape, colour and pin count do not prove electrical compatibility. Pinout, wire gauge, current and voltage rating, mating family and the system documentation all have to agree before you connect anything. Our installation mistakes guide covers the crimping and routing side.

The Short Comparison

Families, not grades. A connector belongs to a circuit before it belongs to a product.

Match the circuit, then the family, then the pinout. Doing it in any other order is how people end up with a plug that mates and a system that does not work.

What Each Cable Actually Carries

Battery to controller carries high-current DC. Polarity matters absolutely, the conductors are heavy, and the wire gauge and crimp quality are part of the circuit rather than incidental to it. Controller to motor carries three-phase power on three conductors, and the order in which those phases connect affects how the motor runs. Controller to accessories carries low-current signals for display, throttle, pedal-assist sensor, brake cut-offs and hall sensors, where the risk is not heat but getting a function on the wrong pin. Our guide to hub motor internals covers how phases and hall signals work together.

The reason to separate them mentally is that they fail differently. A high-current connection fails through resistance and heat. A phase connection fails through wrong order, producing rough running or reverse rotation. A signal connection fails through wrong pin function, producing anything from no response to a supply voltage arriving somewhere it should not.

XT90: Battery and Power Connections

XT90 is the larger sibling of XT60 in the same family, and the two are not interchangeable — the physical size differs and so does the current the contacts and wire are built to carry. If you are unsure which you have, compare the housings side by side rather than guessing from a photograph, because the proportions look similar in isolation.

XT90-S anti-spark deserves a mention because it exists for a real reason. Connecting a battery to a controller with large input capacitors produces an inrush current as those capacitors charge, which is the spark and click you hear on connection. An anti-spark version includes a resistance path that pre-charges the capacitors before full contact, reducing arcing and the pitting it causes over time. It is a durability feature rather than a performance one, and it is worth having on a system you connect and disconnect often. Our battery range lists which connector each pack uses.

Before plugging in a battery connection, check polarity, look for damaged or discoloured housings, check the contacts are clean and unspread, and confirm the wire gauge suits the current. Our BMS amps guide covers establishing what that current is.

MT60: Motor Phase Connections

An MT60 carries the three motor phase wires between controller and motor. All three conductors carry substantial current, so the same gauge and crimp considerations apply as on the battery side, and a poor phase connection produces heat exactly where you cannot see it.

Phase order changes behaviour. Swapping which phase connects where can reverse motor direction or make the motor run roughly, because the controller is energising windings in a sequence that no longer matches the motor. That is why a controller or motor swap is not simply a matter of making the plug mate. On systems with a self-learning function, the correct route after a swap is to run the documented learning routine rather than experimenting with phase combinations by hand.

Signs of a poor phase connection are consistent: heat at the connector after a ride, discoloration of the housing, intermittent power under load, rough running that comes and goes, or a connector that feels different to insert than its pair. Any of those means stop and investigate rather than continuing to ride.

Julet and Higo: Waterproof Does Not Mean Universal

These are families of waterproof connectors used across the industry for signal wiring, in sizes from two pins up to eight, nine or ten pins on main and motor harnesses. Their appeal is sealing and a positive locking action, and their trap is that a family is not a wiring standard. Two connectors from the same family, with the same pin count, can carry entirely different functions on the same physical contacts. Julet and Higo-style parts can also look close enough to be confused while differing in keying or contact arrangement. Our displays and controllers range lists what our own harnesses use.

On waterproofing itself, be precise about what an IP rating covers. It describes a correctly mated, undamaged connector with its seal intact. It is not permission to leave an unmated half exposed to weather, to force two halves together when the keying resists, or to pressure-wash the system. An unmated connector should be capped or protected, and a connector that has been forced is usually a connector with a displaced seal.

How to Match a Connector Without Guessing

Never identify a pin function by wire colour. Colour conventions vary between manufacturers, generations and production runs, and the same colours appear in different roles across parts that look identical. If you cannot establish a function from documentation, ask the supplier before connecting. Government guidance identifies modification or repair with non-compatible parts as a factor that raises fire risk (GOV.UK), and connectors are where that most often happens.

KirbEbike Connector Map: What to Ask For

Our harness diagrams label each connector by its job — battery lead, phase cables, hall sensor, throttle, PAS, display, e-brake and self-learning — and the battery plug differs by controller: the official diagrams show XT90 on one controller and XT60 on another, and our phase extensions use 5.5mm bullets and XT150. Pinouts and wire gauges are not printed on them, and harnesses change between controller generations, so ask us for the fields below for your exact system before you order a part.

Ask for these fields for your exact controller generation rather than inferring them from a similar-looking part.

Common Connector Problems

The connector fits but nothing works. Usually a pinout or protocol mismatch rather than a fault. The shells mate because they belong to the same family; the functions behind them do not line up. Recheck the pinout for both halves before suspecting a component.

Motor judders or runs backward after a controller swap. Phase order, most likely. On a system with self-learning, run the documented routine rather than swapping phase wires to find a combination that works.

Connector gets hot under load. Treat this as a fault, not a characteristic. Heat at a connection means resistance there, and resistance at high current means a loose contact, a poor crimp, corrosion or undersized wire. Power lost in a joint rises with the square of the current, so a connection that is merely warm at moderate load can be a serious problem at full draw. Stop riding and investigate (GOV.UK).

Water or corrosion inside a waterproof connector. Means the seal has been compromised, usually by a damaged housing, a forced mating, an unmated half left exposed, or pressure washing. Do not simply dry it and carry on — inspect the contacts for corrosion and pitting, and replace rather than clean if the contact surfaces are damaged.

Connector and Cable Options to Compare

Four routes, listed alphabetically and judged on the same criteria: what they supply, how compatibility is established and the main limitation.

1. AMASS XT and MT Connectors

AMASS is the manufacturer behind the XT60, XT90 and MT60 families, and genuine parts come with a published data sheet for each variant — standard, anti-spark XT90-S, panel-mount and PCB versions. That is exactly the evidence this article asks for: a current and voltage rating for the specific part rather than the number in the name. Buy through an authorised electronics distributor, check the variant code against the data sheet, and remember the wire and crimp still set the real limit.

2. Generic Marketplace Connectors

The large category of XT-family, MT-family and Julet-style connectors and pigtails sold loose. They are cheap, widely available and often exactly what you need for a repair. The cautions are consistent: listings frequently give a family name without a manufacturer, current ratings are quoted without a data sheet, pin arrangements vary between production runs of visually identical parts, and crimp quality on pre-terminated pigtails is variable. Buy on the manufacturer part where you can.

3. Higo Waterproof Connectors

Higo makes waterproof e-bike connectors and cable assemblies used by major drive-system brands, which makes it the reference point for sealed signal and harness plugs. Higo and Julet-style plugs can mate physically while carrying a different pin sequence, so a Higo part is not automatically a drop-in for a Julet one. Confirm the series, pin count and pinout for both halves before ordering.

4. KirbEbike Harnesses and Cables

Our kits are supplied with matched harnesses, and replacement cabling is available through the displays and controllers range. Our official harness diagrams label every plug by function, and the battery plug varies by controller (XT90 or XT60), so request the connector map for your exact controller generation rather than working from a similar part. Buying a complete kit avoids the question entirely, since the harness arrives matched to the controller and motor.

Listed alphabetically. In every case, confirm the specific mating part rather than the family.

Final Matching Checklist

One unknown is enough to stop and ask. A connector is cheap; a controller is not.

Conclusion: Match the Circuit, Rating and Pinout — Not the Shape

XT90, MT60 and Julet are not competing options. XT90 handles high-current battery and power connections, MT60 carries three motor phases, and Julet and Higo families handle low-current signals and some combined motor harnesses. Choosing between them is not a decision — it follows from which circuit you are working on.

What is a decision is whether you verify before connecting. Identify the circuit, record the family, pin count, keying and gender, verify the pinout with orientation stated, check the rating against the manufacturer data sheet rather than the number in the name, size the wire for the current, and confirm the exact mating part. Never match by wire colour, never force a plug that resists, and treat any warm connector as a fault. Use only components specified for each other (GOV.UK).
