Published 29 April 2025 · Updated 30 April 2025 · 5 min read

Beginner’s Guide to 36V, 48V, 52V, and 72V Ebike Batteries: Which Voltage Is Right for You?

Unlock £10 Off Today

kirbEbike10

ltage (V), battery capacity (amp-hours or Ah), and total energy (watt-hours or Wh). The formula is straightforward: Wh = V × Ah.

Stay In The Know

Expert advice. Very good deals. The absolute best (and worst) things we've tested lately.

ltage (V), battery capacity (amp-hours or Ah), and total energy (watt-hours or Wh). The formula is straightforward: Wh = V × Ah.

Voltage	Battery Capacity (Ah)	Top Speed (km/h)	Typical Range (km)
36 V	13 Ah	30–35	40–70
48 V	11.6 Ah	45–50	35–45
52 V	20 Ah	50–60	40–60
72 V	20 Ah	75–85	40–80

UK Rules for E-Bike Power

In the UK, Electrically Assisted Pedal Cycles (EAPCs) must follow specific rules: motors cannot exceed 250 W continuous power, pedal assistance is required, and motor support must stop at 25 km/h. KirbEbike 36 V/250 W kit complies with these regulations. However, their 48 V, 52 V, and 72 V kits go beyond these limits and are intended for off-road or private use only.

Up next, we’ll break down the pros and cons of each voltage option and where they work best.

Watts, Amp Hours ("Ah"), and Volts Explained for Electric Bikes

Battery Voltage Options: 36V to 72V

Here’s a breakdown of KirbEbike's battery voltage options:

36V Batteries for Everyday Use

KirbEbike's 36V kit (starting at £322) complies with UK e‑bike regulations, offering a top speed of 25 km/h and a range of 30–40 km per charge.

48V Batteries for Versatility

The 48V 1000W kit (starting at £494) strikes a balance between speed and range, reaching 45–50 km/h with a range of 35–45 km per charge. However, it loses power noticeably once the battery drops below 50% charge.

52V Batteries for High Performance

For those seeking more power, the 52V 1500W kit (starting at £590) achieves speeds of 50–60 km/h and a range of 40–60 km per charge. It also offers consistent power output throughout its charge cycle.

72V Batteries for Off‑Road Adventures

The 72V 4000W kit (starting at £906) is designed for off‑road enthusiasts, delivering speeds of 75–85 km/h and a range of 40–80 km per charge. Keep in mind, this option is not road legal.

Battery Voltage Comparison Chart

Voltage	Ideal Use	Advantages	Drawbacks
36V	City rides	Meets UK speed limits, budget-friendly	Limited speed and range
48V	Urban and light trails	Good mix of speed and range	Power drops below 50% charge [1]
52V	High-speed rides	Consistent power, better efficiency	Higher initial cost
72V	Off‑road use	Maximum speed and power	Not suitable for road use

The 48V battery experiences a noticeable drop in power once it’s half discharged, whereas the 52V battery maintains a steadier performance.

Selecting Your Battery Voltage

Choosing the right battery voltage depends on how you plan to use it. Consider your commute distance, the type of terrain, and the load you’ll carry.

36 V/250 W (starting at £307): Ideal for road use, short commutes up to 25 km, and flat terrain.
48 V/1,000 W (starting at £379): Suitable for mixed terrain and moderate hills, with a range of 35–60 km.
52 V and above: Designed for heavy loads or high speeds. A 60 V system can handle cargo runs up to 80 km.

Power vs Range Trade-Offs

Voltage plays a key role in determining both power output and range. Here's a quick comparison:

Voltage	Typical Range	Power Output	Best For
36 V	30–40 km	250 W (up to 500 W)	Daily commutes
48 V	35–60 km	750–1,000 W	Mixed terrain and moderate hills
52 V	Varies by Ah	1,500–2,000 W	High-performance needs
72 V	40–80 km	3,000–4,000 W	Off-road and high-speed riding

UK Regulations and Off-Road Use

In the UK, only 36 V/250 W systems comply with EAPC regulations (≤250 W, ≤25 km/h). Systems with 48 V or higher exceed these limits and are restricted to off-road or private land use .

Once you've chosen your voltage, focus on proper setup and maintenance to ensure your system performs well and lasts longer.

Battery Setup and Care

Once you've chosen your voltage, proper installation and regular maintenance are key to keeping your system safe and reliable.

Matching Components

Always ensure the voltages of your battery, motor, and controller match perfectly (e.g., a 48 V battery should pair with a 48 V motor and controller).

In October 2024, Christy Lynch installed a KirbEbike mid-drive kit on a Vitus Dee Nexus-3. By matching all components to 48 V, she experienced smooth hill climbs without any issues.

Safety and Upkeep

Take specific steps to maintain your battery in the UK's climate:

Condition	Recommended Action	Why It Matters
After wet rides	Dry all connections thoroughly	Prevents oxidation and corrosion
Cold weather	Warm battery to room temperature before charging	Protects battery cells
Regular use	Charge after each ride	Maintains optimal cell condition
Long-term storage	Keep at around 60 % charge, room temperature	Extends battery life

Battery End-of-Life Care

When your battery can no longer hold a charge, make sure to dispose of it responsibly. You can return used batteries to KirbEbike or take them to a local recycling centre for safe disposal.

To maximise battery life, charge it when it drops to 30–60 % capacity during regular use. For storage, keep the battery charged at 75–80 % in a dry location with a temperature range of 0–40 °C.

Explore KirbEbike's Top Ebike Batteries by Voltage

Still not sure which setup is right for you? Here's a breakdown of KirbEbike’s top battery and conversion kits to help you make the right call—whether you’re commuting, climbing hills, or tearing up trails.

36V Battery Kits for Road Legal Use

If you're looking for a UK road-legal ebike, the 36V setup is your best choice. While KirbEbike specializes in performance kits, you can contact them directly for a compliant 36V/250W build.

48V Ebike Kits – Best for Versatile Urban Riding

Need more power for mixed terrain or delivery routes? The 48V 1000W ebike kit is a top seller, delivering speeds up to 45–50 km/h with excellent reliability.

Motor Power: 1000W
Speed: 45–50 km/h
Range: 35–45 km per charge
Ideal for: Moderate hills, weekend riding

52V Ebike Batteries – High Performance, Better Efficiency

Looking for that sweet spot between power and consistency? The 52V 2000W MTX Rim Kit is made for riders who want speed and stamina.

Motor Power: 2000W
Speed: 50–60 km/h
Range: 40–60 km
Features: Consistent torque, even at lower charge levels

72V Batteries – For Extreme Off-Road Power

For serious thrill-seekers, the 72V 4000W ebike kit delivers unmatched speed and torque. This high-voltage ebike battery setup is ideal for rugged trails and private tracks.

Motor Power: 4000W
Top Speed: 75–85 km/h
Range: 40–80 km
Controller: 72V, 60A smart controller

Why Trust KirbEbike for Your Setup?

Whether you're upgrading to a 52V performance ride or sticking with a 48V city commuter, KirbEbike offers expertly matched kits with plug-and-play simplicity, UK support, and free shipping.

Making Your Final Choice

Feedback from actual users supports the criteria we've discussed. The table below helps you match your riding style with the right voltage:

Riding Style	Recommended Voltage	Typical Range	Best For
Urban Commuting	36V / 48V	20–35 miles	Daily rides on mostly flat roads
Mixed Use	48V / 52V	25–50 miles	Weekend trips and moderate hills
Heavy Duty	60V / 72V	40–70 miles	Delivery work and navigating steep terrain

Combine this with the maintenance tips and criteria mentioned earlier to make your final decision. If you're unsure, reach out to KirbEbike support for tailored advice specific to the UK.
